TECK
PROFILE

The Teck profile combines the appearance of the traditional shingle roof with all the features of modern constructions.

Aesthetical, lightweight and watertight, this type of roof is ideal for houses built in rural or mountainous areas, contributing to the rustic specificity of the area.

Technical information

  • Profile type
    Teck
  • Material
    Pre-painted steel sheet
  • Steel class
    minimum S250GD
  • Weight (kg/m²)
    4.5
  • Available thickness (mm)
    0.5
  • Useful width (mm)
    1200
  • Minimum zinc coverage (g/m²)
    275
  • Exterior paint coating (µm)
    Super Matt Polyester 35
    PUR NOVA 55
  • Corrugation (wave) height (mm)
    30
  • Step length (mm)
    370
  • Minimum slope (˚)
    16
  • Teck Profile - Section

Metallic tiles options

Anthracite Grey

We continue to expand the Metigla colour palette. Due to the increasing demand and popularity of grey shades, Anthracite Grey (RAL 7016) is now available in a MAT version, with a paint thickness of 35 µm, for any product belonging to the Metigla Residential and Industrial divisions.

PUR NOVA

PUR NOVA is available in Grey (RAL 7024), Brown (RAL 8017), Dark Brown (RAL 8019) and Black (RAL 9005) and stands out for its premium paint quality55 µm thickness of the paint layer, increased strength against scratches and extended protection against depigmentation, being one of the most durable finishes.

TECK COLOR

Super Matt Polyester

20 YEARS WARRANTY

Wine Red

RAL 3005

Oxide Red

RAL 3009

Chrome Green

RAL 6020

Anthracite Grey

RAL 7016

Copper Brown

RAL 8004

Brown

RAL 8017

Grey Brown

RAL 8019

Black

RAL 9005

PUR NOVA / PUR

30 YEARS WARRANTY

Anthracite Grey

RAL 7016

Brown

RAL 8017

Grey Brown

RAL 8019

Black

RAL 9005

Steel type and structure

The raw material used by Metigla in the production process is hot galvanized steel (1), with a zinc protection of at least 275 g/m² (2).
The zinc coating is protected through multilayer technology with a passivated coating (3), primary protective coating (4) and paint layer (5).

The top protective layer (5) is available in PUR MAT (mat polyurethane) of 50 μm.

On the bottom side, the paint coating is 10 μm Polyester or Acrylic (6).

FINISHING PARTS

  • Eaves closure

  • Valley

  • Verge trim

  • Inner verge trim

  • Wall ridge

  • Snow guard
